Home > PRODUCTS

Relock Disc

Abrasives:
Aluminum Oxide
Calcinated A/O
Zirconia
Outside Dia.:
25mm/38mm/50mm/75mm
Backing Type:
Type R
Type S
Facebook Twitter Google+ LinkedIn

Introduction

Item No.: KD6110



Abrasive Grain

Base

Grit Gange

Dia.

Hole Dia.

Max R.P.M.

Types

Aluminum Oxide

Plastic

P40--P400

2" (50mm)

5/8" (16mm)

15200

R

3" (75mm)

5/8" (16mm)

15200





Item No.: KD6120



Abrasive Grain

Base

Grit Gange

Dia.

Hole Dia.

Max R.P.M.

Types

Heated Aluminum Oxide

Plastic

P40--P400

2" (50mm)

5/8" (16mm)

15200

R

3" (75mm)

5/8" (16mm)

15200





Item No.: KD6131



Abrasive Grain

Base

Grit Gange

Dia.

Hole Dia.

Max R.P.M.

Types

Zirconia Aluminum

Metal

P36--P120

2" (50mm)

5/8" (16mm)

15200

R

3" (75mm)

5/8" (16mm)

15200





Item No.: KD6140



Abrasive Grain

Base

Grit Gange

Dia.

Hole Dia.

Max R.P.M.

Types

Ceramic Oxide

Plastic

P36--P120

2" (50mm)

5/8" (16mm)

15200

R

3" (75mm)

5/8" (16mm)

15200



Parameter

Applicable Industries:


■ Chemical and processing industries ■ Fitting and container construction

■ Steelworks ■ Foundries ■Tool and mould construction

■ Pipeline construction ■Dockyards ■ Automotive industry

■ Steel construction, locksmiths

■ Aviation and aerospace, gas turbine construction and repair

■ Machine engineering










Grit Recommended:


Grit

Spec.

Applications

Suggested Progress

P60 P80

Coarse

For removal and leveling of moderate surface imperfections

■Derusting ■Deburring

P100-- P240

Medium

For smoothing and light removal on bare surfaces

■GrindingCleaning

P320 P400

Fine

For bare surface cleaning and finishing

Cleaning ■Polishing



Introduction for Abrasives :


A/O: Alumimun Oxide

Aluminum Oxide grain which has high efficiency grinding performance. Cotton cloth base synchronous consumption fast, does not burn the workpiece.Glassfiber backing and plastic backing available.

With efficient grinding and polishing effect, the product is windly applied in the metal, stainless steel, wood, etc


C/O: Ceramic Oxide

With high quality ceramic grinding grain, which can quickly and efficiently finish the surface treatment of the workpiece. It has excellent effect for polishing the stainless steel.Glassfiber backing and plastic backing available.


Z/A: Zirconia Alumia

For grinding the stainless steel workpiece, the zirconia grain with outstanding effect and high efficiency. In addition to stainless steel, it is also used for the metals.Glassfiber backing available.


Safety Instructions

 Instructions:
1. Please try to choose operation indoors environment which without clutter phenomenon. The user should also concentrate on the operation to avoid an accident. If use it at outdoor, try to choose a quiet environment.
2. During the grinding process, the workpiece should be kept parallel to the working water level.

3. The user's power should be evenly distributed when operation. Never suddenly heavy and lightly.

4. Avoid moving or slipping the workpiece during grinding.





Warning:

1. Must wear dustproof mask and goggles  when working.

2. Never exceed the maximum safe speed.

3. Discs must be mounted correctly and used with metal guards and goggles.
